specification:
· 220V 7.5A AC AC
· 110V 15A AC AC
· Switch Life: Intermittent than 100 million times
· Tank pressure: equal to the atmospheric
· Temperature range: 4 ° C ~ 80 ° C
Features:
Base is provided with 3/4 "and 1" two-stage spiral tooth catheter directly fitted, with L-bracket to the mounting surface.
Switch is sealed by the housing, completely moisture and maintain accurate performance and extend the life of the switch.
Entity hammer ball immersed in water, stable center of gravity, not float on the water, and high accuracy.
Switch is provided with A .B. Two circuits, A terminal used for water supply, B terminals for pumping.
installation method
1. Controller Optimum fixed position should be at the top of the sink central intending fixed in the tank sidewall needed to avoid the hammer the ball hit the wall and the groove.
2. The plumb bob system controller pull line, controlled by the central range of the ball on to the lower central portion of the ball, as needed can be freely adjusted.
1. Controller Optimum fixed position should be at the top of the sink central intending fixed in the tank sidewall needed to avoid the hammer the ball hit the wall and the groove.
2. The plumb bob system controller pull line, controlled by the central range of the ball on to the lower central portion of the ball, as needed can be freely adjusted.
